Standard Manual Jack Plate (up to 40hp)

Name: Standard Manual Jack Plate (up to 40hp)
Brand: My Store
SKU: SMJP-01
Price: 599.00 USD
Availability: InStock

Standard Manual Jack Plate (up to 40hp)

$599.00

Sale Sold out

Shipping calculated at checkout.

The Standard Manual Unit fits if:

Outboard motor weights 150 lbs or less
The mounting bracket is 10 ¾ inches wide or less
Your motor is 8-20 hp, with or without:
- Factory trim and tilt
- Manual tilt gas shock assist
Your motor is 25-40 hp and does not have:
- Factory trim and tilt
- Manual tilt gas shock assist

Important: Your motor must meet all three requirements: weight, mounting-bracket width and horsepower/tilt configuration.

Not Compatible with:

25–40 hp motors with factory power trim and tilt or manual tilt gas shock assist
Motors weighing more than 150 lbs
Motors with mounting brackets wider than 10 ¾ inches

If your motor meets any of these conditions, you will need the Large Unit

Not Sure? Confirm Your Fit With Our Jack Plate Finder Quiz

Why Boaters Choose On The Fly

Adjust motor height on the water without tools
Reduce drag and increase fuel efficiency and handling
Reach shallower water with more confidence
Protect your lower unit and propeller
Fine-tune performance for changing loads and water conditions
Durable marine-grade aluminum construction

Feel free to contact us for guidance!

Product Specifications

- Motor Size: Fits 8–20 HP motors with or without factory power trim and tilt or manual tilt gas shock assist
- 25–40 HP Motors: Fits only motors without factory power trim and tilt or manual tilt gas shock assist
- Maximum Motor Weight: 150 lbs
- Motor Mounting-Bracket Width: Your motor’s mounting bracket must be 10¾ inches wide or less at its widest point.
- Material: Durable, corrosion-resistant marine-grade aluminum
- Pre-Drilled Mounting Holes: 8 inches apart horizontally and 8¼ inches apart vertically
- Warranty: 3-year housing warranty and 1-year jack warranty

Weight and Dimension

- Weight: 23 lbs
- Height: 10 ½ inches
- Width (Transom Side): 12 ½ inches
- Width (Motor Side): 13 ¼ inches
- Setback/Width: 5 inches from transom to motor slide back
- Motor Plate Height: 12 ½ inches
- Motor Mounting Plate (Inside Brackets): 10 ¾ inches
- Max Rise (Travel): 5 ½ inches, with potential for up to 7 ¾ inches depending on mount location.

Accessories Not Included

(Not Included): Transom mounting accessories
- 4 stainless steel bolts (½” x 3 ½”)
- 4 stainless steel lock nuts (½”)
- 8 stainless steel flat washers (½”)
- Motor clamp spacers
